Variables let you wire data through your agent. Any field in any step that shows {{Steps.StepName.Property}} as a placeholder accepts a variable expression. Type {{ in that field to open autocomplete and browse everything available at that point in the agent.
Syntax
All variable expressions use double curly braces:
| Part | What it means |
|---|
{{ }} | Marks the start and end of an expression |
Namespace | The category of data (see table below) |
Path | Dot-separated path to the exact value |
Get File becomes {{Steps.Get_File.FileContent}}.
Namespaces at a glance
| Namespace | What it contains | Example |
|---|
Variables | Custom inputs defined on the Input step | {{Variables.CustomerName}} |
Steps | Outputs from any previous step | {{Steps.Parse_Doc.MarkdownContent}} |
Inputs | Outputs from directly connected parent steps only | {{Inputs.My_Step.Value}} |
Execution | Runtime metadata (IDs, timestamps) | {{Execution.executionId}} |
User | Identity of the person running the agent | {{User.email}} |
Helpers | Utility functions available at runtime | {{Helpers.currentDateTime}} |
InputSchema | Fields from a Tool Interface input schema | {{InputSchema.ticketId}} |
PromptVariables | Template slots in prompt segments | {{PromptVariables.tone}} |
Input variables are declared on the Input step and filled in by whoever runs the agent — a user in chat, an API caller, or an upstream step.
Defining them: Open the Input step → Variables tab → click Add Variable. Give it a name, choose a type (String, Number, Integer, URL, Email), and optionally write a description so callers know what to provide.
Using them downstream: Reference them anywhere in the agent with {{Variables.YourVariableName}}.
{{Variables.CustomerEmail}}
{{Variables.OrderId}}
{{Variables.MaxResults}}
The variable name you define on the Input step is exactly what you type after Variables. — casing is preserved.
Set Variables — updating values mid-run
The Set Variable step lets you assign a new value to an input variable at any point in the agent. Use it when a step produces data you want to carry forward under a consistent name.
Workflow:
- The variable must already exist on the Input step (create it there first, or click Create New Variable directly from the Set Variable step panel).
- Add a Set Variable step where you want the assignment to happen.
- Select the variable from the dropdown and set its value — you can hardcode it or use an expression like
{{Steps.My_Step.Result}}.
- Downstream steps read the updated value via
{{Variables.Name}} as usual.
| Input Variables | Set Variables |
|---|
| Where defined | Input step → Variables tab | Set Variable step |
| When set | Before the agent starts | At a specific point mid-run |
| Who provides the value | External caller (user, API, upstream agent) | The agent itself, from step outputs |
| Syntax to read | {{Variables.Name}} | {{Variables.Name}} (same namespace) |
| Typical use | Receive user input, API parameters | Store intermediate results, counters, accumulated text |
Step Outputs — {{Steps.StepName.Property}}
Every step produces one or more output properties. Reference them in any downstream step using the step’s title (spaces → underscores) and the property name.
{{Steps.Download_File.FileContentBase64}}
{{Steps.Parse_Document.MarkdownContent}}
{{Steps.AI_Model.Value}}
{{Steps.Get_Order.OrderStatus}}
Steps gives you access to all previous steps in the agent, not just the ones directly connected. If you only want to reference outputs from a step that is directly wired to the current one, use Inputs instead — the behaviour is identical but the scope is narrower.
Array access
When a step returns an array, use bracket notation to access individual elements:
{{Steps.My_Step.Results[0].Name}} — first item
{{Steps.My_Step.Results[-1].Name}} — last item
Execution context — {{Execution.*}}
Always available. No setup required.
| Variable | Type | Description |
|---|
{{Execution.executionId}} | string | Unique ID for this agent run |
{{Execution.conversationId}} | string | ID of the conversation session |
User context — {{User.*}}
Available when the agent is run by an authenticated user.
| Variable | Type | Description |
|---|
{{User.id}} | string | User’s unique identifier |
{{User.name}} | string | User’s display name |
{{User.email}} | string | User’s email address |
{{User.roles}} | string[] | Roles assigned to the user |
{{User.groups}} | string[] | Groups the user belongs to |
Helpers — {{Helpers.*}}
Runtime utilities that generate values on demand.
| Variable | Description |
|---|
{{Helpers.currentDateTime}} | Current date and time at execution |
Autocomplete
Any field that supports expressions shows autocomplete when you type {{. The autocomplete list updates as you type:
- Type
{{ to see all top-level namespaces
- Type
{{Steps. to see every available previous step
- Type
{{Steps.My_Step. to see all properties that step exposes
- Continue typing to filter the list
The autocomplete only shows steps that come before the current step in the agent — you cannot reference outputs from steps that haven’t run yet.
Mixing expressions and plain text
Expressions can be embedded inside longer strings. Everything outside {{ }} is treated as literal text:
Hello {{Variables.FirstName}}, your order {{Variables.OrderId}} is {{Steps.Check_Status.Status}}.
Common mistakes
Using Inputs when you mean Steps
Inputs only includes outputs from steps that are directly connected to the current step via an edge. If the step you want is two or more hops away, use Steps.
Referencing a step that runs after the current one
The autocomplete only surfaces steps that come before the current step. If a step doesn’t appear, it either hasn’t run yet or is not on a path that leads to the current step.
Wrong casing or space handling
Step names are case-sensitive and spaces become underscores. A step titled Send Email must be referenced as {{Steps.Send_Email.Property}}.
Expecting a single value from an array
If a step returns a list, {{Steps.My_Step.Items}} gives you the whole array. Use [0] or [-1] to get a specific element, or pass the array into a Loop step to process each item individually.
Using {{Variables.Name}} before it has been set
If a variable is defined on the Input step but not filled in by the caller, it arrives as an empty string. Use a Set Variable step earlier in the agent to assign a default if needed.
